Length: 418 mm (16.5 in.) Width: 328 mm (13.0 in.) Height: 588 mm (23.2 in.) Weight: 18 kg (39.7 lbs.)
Electronic shutter effect: Strobe effect, pulse effects, instant open and blackout
Electronic dimming: 0 - 100%, four dimming curve options
Color wheel 1: 7 colors plus open, rotation with variable direction and speed
Color wheel 2: 7 colors (incl. 1 x UV, 2 x CTC) plus open, rotation with variable direction and speed
Rotating gobo wheel: 7 gobos plus open, wheel rotation, gobo indexing, rotation and shake
Static gobo wheel: 8 gobos plus open, wheel rotation and shake Iris:
Motorized Prism: Indexing and rotation with variable direction and speed
Pan: 540° Tilt: 270° Pan and tilt speed: Adjustable via onboard control panel and DMX Focus:
Motorized Control options: DMX, standalone Setting and addressing: Control panel with backlit graphic display DMX channels: 17 Standalone trigger options: Music trig, auto trig
Standalone sequences: 4 pre-programmed shows Standalone memory: 20 scenes Music trig sensitivity: Adjustable DMX compliance: USITT DMX512/1990
Light source: 180 W LED engine Minimum LED lifetime: 20,000 hours (to >70% luminous output)* *Figure obtained under manufacturer´s test conditions.
Efficacy: 25.5 lumens per watt Cut-off angle: 16° Total output: 7100 lumen
Housing: High-impact flame-retardant thermoplastic Color: Black Protection rating: IP20
Gobo diameter: 26.8 mm +/- 0.2 mm (1.1 in. +/- 0.008 in.) Maximum image diameter: 22.0 mm (0.87 in.) Gobo thickness, minimum: 0.3 mm (0.01 in.) Gobo thickness, maximum: 3.5 mm (0.14 in.) Gobo material: Steel, aluminum or borosilicate glass
Mounting points: Two quarter-turn brackets for rigging clamps Location: Dry location only, must be fastened to surface or structure Orientation: Any
AC power: 100-240 V nominal, 50/60 Hz Typical total power consumption: 300 W Power consumption figures are typical, not maximum. Allow for +/-10% variation.
Cooling: Forced air, temperature controlled Maximum ambient temperature (Ta max.): 40° C (104° F) Minimum ambient temperature (Ta min.): 0° C (32° F) Total heat dissipation (calculated, +/- 10%): 1010 BTU/hr. (at full intensity, full white)
EU safety: EN 60598-2-17 (EN 60598-1), EN 62471, EN 62493 EU EMC: EN 55015, EN 55103-1, EN 55103-2, EN 61000-3-2, EN 61000-3-3, EN 61547 US safety: UL 1573 US EMC: 47 CFR Part 15 Class A Australia/NZ: RCM
Power cable, 1.5 m (4.9 ft.), without mains plug
Two Omega clamp attachment brackets with 1/4-turn fasteners
Power connectors: Power Connector PowerCON Male: P/N 91611795
Power Connector PowerCON Female : P/N 91611794
Cables, 16 A, for connection to power in chains: Power relay cable 3 x 2.5 mm2, H07RN-F POWCON-POWCON 1.2 m (3.9 ft.): P/N 91611798
Power relay cable 3 x 14 AWG, SJOOW POWCON-POWCON 1.2m (3.9 ft.): P/N 91610175
Power relay cable 3 x 2.5 mm2, H07RN-F POWCON-POWCON 2.5m (8.2 ft.): P/N 91611799
Power relay cable 3 x 14 AWG, SJOOW POWCON-POWCON 2.5m (8.2 ft.): P/N 91610176
Cables, 16 A, for power input: Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 1.5 m (4.9 ft.): P/N 91611800
Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 1.5 m (4.9 ft.): P/N 91610177
Power input cable 3 x 2.5 mm2, H07RN-F OPEN-POWCON 5.0 m (16.4 ft.): P/N 91611801
Power input cable 3 x 14 AWG, SJOOW OPEN-POWCON 5.0 m (16.4 ft.): P/N 91610178
(H07RN-F are European approved cables, SJOOW are US approved cables)
Installation hardware: G-clamp (suspension with fixture hanging vertically downwards only): P/N 91602003
Quick trigger clamp (suspension with fixture hanging vertically downwards only): P/N 91602007
Half-coupler clamp: P/N 91602005
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, black: P/N 91604006
Safety Cable, SWL 60 kg, BGV C1 / DGUV 17, silver: P/N 91604007
Martin™ RDM 5.5 Splitter: P/N 90758150 Martin Companion Cable: P/N 91616091 Martin Companion Software Suite (including firmware uploader): Free download from www.martin.com
