DBX

dbx 231s Dual Channel 31-Band Equalizer

dbx 231s Dual Channel 31-Band Equalizer

$2,500.00 TTD
$2,500.00 TTD
Sale Sold out
Taxes included. Shipping calculated at checkout.



Exceptional sound and rugged reliability




When the pros need an EQ, they turn to dbx. With a proven track record that spans four decades, dbx® EQs are the industry standard for touring, studios, and audio installations. With the dbx heritage of revered pro EQs, the 231s meets the needs of the most demanding sound reinforcement environments, while offering the simplicity of straightforward controls.

The dbx 231s includes two 31-band channels of 1/3-octave equalization, ±12 dB input gain, switchable ±6 dB or ±12 dB boost/cut range, 20mm nonconductive sliders, an intuitive user interface, and output level metering. From its extended 10Hz to 50kHz frequency response and 112 dB dynamic range to the quality componentry and meticulous attention to detail, the 231s offers exceptional sound and rugged reliability that guarantees you will always sound your best.

Sure to find a home in the studio, on tour and with installed sound venues, the dbx 231s is destined to take its rightful place in the lineage of great dbx signal processors that are the professional's choice in signal processing. With such affordable quality, there's no longer any excuse for compromising your sound.



Recommended for: Portable, Tour.

    Dual 31-band, 1/3-octave Constant Q frequency bands

    Switchable boost/cut ranges of ±6 or ±12 dB

    Front panel bypass switch

    ±12 dB input gain range

    4-segment LED ladders for monitoring output levels

    XLR and TRS Inpts and Outputs

    Frequency Response of <10Hz to >50kHz

    Dynamic range of greater than 108dB



Input Connectors        1/4" TRS, female XLR (pin 2 hot)

Input Type       Electronically balanced/unbalanced, RF filtered

Input Impedance        Balanced 40k ohm, unbalanced 20k ohm

Max Input       >+21dBu balanced or unbalanced

CMRR >40dB, typically >55dB at 1kHz

Output Connectors     1/4" TRS, male XLR (pin 2 hot)

Output Type    Impedance-balanced/unbalanced, RF filtered

Output Impedance     Balanced 100 ohm, unbalanced 50 ohm

Max Output     >+21dBu balanced/unbalanced into 2k ohm or greater; >+18dBm balanced/unbalanced (into 600 ohm)

Bandwidth      20Hz to 20kHz, +0.5/-1dB

Frequency Response   <10Hz to >50kHz, +0.5/-3dB

Dynamic Range           Typically >112dB

Signal to Noise Ratio   Typically >95dB

THD+Noise      <0.003%

Interchannel Crosstalk            <-90dB, 20Hz to 20kHz

Bypass Switch Bypasses the graphic equalizer section in the signal path

Low cut Switch            Activates the 50Hz 12dB/octave high-pass filter

Range Switch Selects either +/- 6dB or +/-12dB slider boost/cut range

Operating Voltage      100-240VAC 50/60Hz

Power Consumption   15W

Power Connector        IEC receptacle

Unit Weight    6.2 lbs.(2.81 kg)

Shipping Weight         7.9 lbs.(3.58kg)

Dimensions     3.5" (8.9cm) H x 6"(15.24cm) D x 19" (48.26cm) W
