AUDIOPRESSBOX APB-P112 SB Passive Portable APB, 1 Line Input, 12 Mic Outputs

AudioPressBox APB-P112 SB

Passive, 1x LINE Input, 12x MIC Outputs



A professional portable passive press box (Audio Splitter) suitable for both indoor and outdoor press conferences.

It features 1 Line Input and 12 MIC outputs.

Each Output is independet transformer balanced and isolated.

It also has a link Output so you can daisy chain more of them in a row if you need additional MIC Outputs.

•  1 balanced LINE Input


• 12 High quality balanced Outputs, each Output is independent transformer isolated


•  AudioPressBox delivers audio in broadcast quality


•  It can be fed directly by a mixing console


•  Source: Balanced Line Output of professional audio equipmentSpecifications of APB-P112 SB



  Type 1 in 12 out

  Groups 1

  Inputs 1

  Input connectors ballanced, XLR

  Max. input level Line: +24dBu

  Input Impedance 2,5kOhm

  Ouputs 12 MIC level (-38dBu) 1 Input link (Line level)

  Ouput connectors ballanced, XLR-M connector

  Transfomer isolated outputs Yes (each output)

  Nominal Output level -38dBu (0dBu on the input)

  Maximum Output level -14dBu (no load) -20dBu (150 Ohm)

  Output Impedance 150 Ohm

  Frequency Response 10Hz to 30kHz/-1dB

  Dimensions (WxHxD) 225x135x95 mm

  Weight 1860g
